Table . 8-1
Wire controller:
If a wire controller is connected, will illuminate;
otherwise will be
Outside solar heat source:
If an outside solar heat source has been
frequency; otherwise will be
Vacation :
Will illuminate if the unit is under vacation mode,
⑥
⑤
No Icon Description
⑦
⑧
E-heater:
Will illuminate if E-heater is activated,
If E-heater is automatically activated by unit,
will illuminate;
If E-heater is manually activated,
with 0.5Hz frequency.
When setting E-heater manually ON/OFF,
Disinfect:
Will illuminate when the unit is under disinfect
Will illuminate if disinfect function is automatically
activated by unit;
is manually activated;
disinfect function or setting disinfect timer.
High temperature alarm:
If set water temperature is higher than 50 C，
Alarm:
When unit is under protection/error,
with 5Hz frequency and sound the alarm. It will sound
3 times every minute until protection/error has been
eliminated or manually press for 1 second.
Lock:
If button is locked, will illuminate,
otherwise will be
.
Temperature unit:
If setting temperature unit as Celsius, will
illuminate, will show celsius degree;
If setting temperature unit as Fahrenheit, will be
illuminate, will show fahrenheit degree.
Press for 10sec, it will change between
and .
If button is under lock mode, press any button
except unlock button, will illuminate.
Will illuminate when setting water
temperature or setting days for vacation.
⑨
⑩
1 1
2 1
Will illuminate if screen is unlocked.
It shows water temperature on normal mode;
It shows remaining vacation days on vacation mode;
It shows setting temperature under setting;
:
Reserved
3 1
8.1 Control Panel Explanation
8.2 Display Explanation
