20
Vacuum the ash deposited in the compartment
under the drawer with a vacuum cleaner.
Unscrew the side ceramic brick to reach the
smoke duct cleaning plates. Unscrew and
vacuum the deposited ash.
Before carrying out the operation described above, clean the tube bundle with the cleaning rods, as
shown in the following gure. Carry out this movement 3-4 times until the rods run without friction.
Lower the cleaning rodsLift up the cleaning rods
The thermostove is a solid fuel heat generator and as such must be checked by a qualied technician
at least once a year at the beginning of the season. The purpose of this maintenance is to make sure
that all the components are in good working order. You are advised to agree an annual contract for the
product with your installer/dealer.
Figure 17.
5 6
