1.3 Exhaust and Fresh Air Intake Locations
Exhaust
Hearth to centre of ue 305 mm
Left Side of unit to centre of ue 139 mm
Centre of unit to centre of ue 148 mm
Fresh Air Intake
Hearth to centre of intake 346 mm
Left Side of unit to centre of intake 370 mm
Centre of unit to centre of intake 83 mm
INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENTING MANUFACTURER
1.4 Safety devices for closed expansion tank system
Systems with closed expansion tank must be tted with:
• Safety valve
• Circulator control thermostat
• Acoustic alarm activation thermostat
• Temperature gauge
• Pressure gauge
• Acoustic alarm
• Automatic thermal regulation switch
• Automatic thermal blockage switch (blockage thermostat)
• Circulation system
• Expansion system (the expansion vessel on the re is sufcient for the re. An extra
vessel may be required depending on the total water volume)
• Safety dissipation system incorporated in the generator with thermal discharge valve
(self-operated), if the device is not tted with a temperature self-regulator.
Automatic lling domestic-type heating devices must be tted with a fuel-blocking thermostat or with
a cooling circuit set by the device’s manufacturer, activated by a thermal safety valve that guarantees
that the highest temperature established by law is not exceeded. The connection between the supply
unit and the valve must be with cut-off devices. The pressure up-stream from the cooling circuit must
be at least 1.5 bars.
Installation recommendations
Warning: Our thermal stoves are tted with 3-litre (Genova, Pisa) and 6-litre (Venezia, Amal ) expansion
tanks. For thermal stoves with a 3-litre expansion tank a further expansion tank with a capacity of at
least 15 litres must be installed in the circuit.
Stoves with a 6-litre expansion tank do not need a further expansion tank if the plant has a maximum
capacity of 60 litres of water; otherwise, in this case also an expansion tank with a capacity of at least
10 litres must be installed.
