2.6.1 Flue
The thermostove functions irrespective of the ue’s draught since it is the smoke engine that conveys
the smoke from the combustion chamber to the ue.
Installation Examples
2.7 Internal Standard Flue Kit (50)
Each 51 External Standard Flue Kit contains:-
ytitnauQnoitpircseDoN traP
1 Galvanised outer liner
ø100mm x 900mm long
2 Stainless steel inner liner
ø75mm x 900mm long
5 Inner/outer ue liner spacer
6w Wall thimble – 2 pieces
ø102mm holes
6s Sot thimble ø107mm hole
7w Wall decor plate
ø102mm hole – white
8 Rain cap 75mm
9 Rain Cap 100mm
26 Lined T-adaptor
This ue kit may be used in new and replacement
applications with the ue penetrating the wall behind
the re, running vertically up an outside wall and
penetrating the sot. The overall height of the f lue is
3.6m. All visible ue has a galvanised nish, and can be
powdercoated on request. Kit is supplied in a carton.
Note: The Davin 51 External Standard Flue
Kit complies with AS/NZS 2918:2001 as per
Applied Research Test Report 05/1185, dated
15 September 2005.
All res must be installed by a qualied
installer as per the manufacturer’s
instructions and AS/NZS2918:2001.
600mm from
roof penetration
External Standard Flue Kit51
Pellet Fire Flue Kits
To order : Telephone 64 3 347 9915. Fax 64 3 347 9916. info@ naturesame.co.nz www.naturesame.co.nz .December 200610
25mm
clearance
I
M
K
C
4
4
2
1
1
1
1
1
1
This ue kit may be used in new and replacement
applications in rooms with stud height of 2.4m.
The overall height of the ue is 3.6m. The visible
ue is nished in black and the ceiling plate is
white. The support angles for securing the liner to
the ceiling are not shown. Kit is supplied in carton.
