Installation Section
Table of Contents
1. Dimensions (Ecoteck Amal) 25
1.1 Deciding where to locate your wood pellet burning heater: 26
1.2 Clearances to Combustibles – Ecoteck Amal Freestanding 26
1.3 Exhaust and Fresh Air Intake Locations 27
1.4 Safety devices for closed expansion tank system 27
2. Installation 29
2.1 Dimensions – Amal Freestanding 29
2.2 Clearances & Specications 29
2.3 Minimum Clearance to Combustibles 30
2.4 Location of the Pellet Fire 30
2.5 Positioning the re: 30
2.6 Installation of the Flue 30
2.7 Internal Standard Flue Kit (50) 31
2.8 External Standard Flue Kit (51) 32
2.9 Hydraulic Installation 33
2.10 Seismic Restraint 35
2.11 Fixing to Timber Floor Framing 35
2.12 How to remove the side panels 36
2.13 Seismic Restraint Locations 37
3. Installation Data Sheet 38
4. Maintenance Record 39
NOTE TO INSTALLER - PLEASE ENSURE THE “INSTALLATION DATA SHEET” ON page 38 IS
COMPLETED ONCE THE UNIT IS INSTALLED.
