EcoxGear EcoBoulder User Manual

Features List
1.
2. Waterproof
3. Bluetooth mode, FM mode, AM mode, AUX 1 mode, AUX 2
mode Optional
4. Bluetooth Connection (Bluetooth V4.0)
5. Music Playing Control
6. Bluetooth Stereo (A2DP/AVRCP)
7. EQ(Default,Bass Boost, Treble Boost, Rock, Jazz) Optional
8. Microphone Input
9. AUX 1, AUX 2 Input
10. USB Charging Ports
11. Master Volume Adjustable(30 levels)
12. Microphone Volume Adjustable(30 levels)
13. Preset the AM/FM Station
14. Store 6 AM Stations
15. Store 6 FM Stations
16. Link Two EcoBoulders
17. Indication(Low battery/Charging/Full charged)
18. Turn On/Off Backlight
19. Bluetooth for 10m distance
Clear and Crystal Sound , Superior Stereo Performance
Bluetooth Compliance
Bluetooth V 4.0
Frequency Band
2.402~2.480GHz ISM Spectrum
Operating Range
Tweeter
W
oofer
Output Power
Modulation
GFSK ,π/4-DQPSK, 8DPSK
Up to 10m (indoor)
3 ' (76.2mm) tweeter'
8 ' (203.2mm) woofer'
50 W (peak)
Battery Capacity
Charging Time
Link
Link Range
12V, 7.0Ah
About 10 hours
TrueWireless Stereo (TWS)
30' (9.1 m) from left to right speaker
Compatibility
Mobile phone/device supporting Bluetooth
V1.1 (and above)
Power Supply
Input voltage: 100-240V~50/60Hz
Size
Radio Frequency Range
504mm*393mm*287mm
US: AM 520 - 1710 kHz, FM 87.5 - 107.9 kHz
Specifications
3
21

EcoxGear EcoBoulder Specifications

General

Bluetooth Compliance	Bluetooth V 4.0
Frequency Band	2.402~2.480GHz ISM Spectrum
Modulation	GFSK, π/4-DQPSK, 8DPSK
Operating Range	Up to 10m (indoor)
Link	TrueWireless Stereo (TWS)
Link Range	30' (9.1 m) from left to right speaker
Radio Frequency Range	US: AM 520 - 1710 kHz, FM 87.5 - 107.9 kHz
Tweeter	3 '' (76.2mm) tweeter
Woofer	8 '' (203.2mm) woofer
Output Power	50 W (peak)
Power Supply	Input voltage: 100-240V~50/60Hz
Battery Capacity	12V, 7.0Ah
Charging Time	About 10 hours
Compatibility	Mobile phone/device supporting Bluetooth V1.1 (and above)

Weight and Dimensions

Size	504mm393mm287mm
