ECS 865-M7 - Advanced BIOS Features

36
Using BIOS
Advanced BIOS Features
This option defines advanced information about your system.
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Phoenix-AwardBIOS CMOS Setup Utility
Advanced BIOS Features
X
X
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
CPU Feature [Press Enter]
Hard Disk Boot Priority [Press Enter]
CPU L3 Cache [Enabled]
Hyper-Threading Technology [Enabled]
Quick Power On Self Test [Enabled]
First Boot Device [Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Boot Other Device [Enabled]
Boot Up Floppy Seek [Disabled]
Boot Up NumLock Status [On]
Gate A20 Option [Fast]
Typematic Rate Setting [Disabled]
Typematic Rate (Chars/Sec ) 6
Typematic Delay (Msec) 250
Security Option [Setup]
APIC Mode [Enabled]
OS Select For DRAM > 64MB [Non-OS2]
HDD S.M.A.R.T. Capability [Disabled]
f
f
123
1
2
3
1
2
3
123
Item Help
Menu Level
f
CPU Feature (Press Enter)
Users please note that this function is only available for Prescott CPUs. Scroll to this
item and press <Enter> to view the following screen:
f
Thermal Management (Thermal Monitor 1)
This item displays CPU’s temperature and enables you to set a safe
temperature to Prescott CPU.
f
f
Phoenix-AwardBIOS CMOS Setup Utility
CPU Feature
Delay Prior to thermal [16 Min]
Thermal Management [Thermal Monitor 1]
TM2 Bus Ratio [0 X]
TM2 Bus VID [0.8375V]
Limit CPUID MaxVal [Disabled]
NX BIOS Control [Disabled]
Item Help
Menu Level
ff
Thermal Monitor 1 (On die
throtting)
Thermal Monitor 2 Ratio
& VID transition
Delay Prior to Thermal (Thermal Monitor 1)
This item enables you to set the delay time before the CPU enters auto
thermal mode.
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6”Fail-Safe Defaults F7:Optimized
