Using BIOS
IDE Primary/Secondary Master/Slave PIO (Auto)
Each IDE channel supports a master device and a slave device. These four items let you
assign the kind of PIO (Programmed Input/Output) was used by the IDE devices. Choose
Auto to let the system auto detect which PIO mode is best, or select a PIO mode from 0-4.
IDE Primary/Secondary Master/Slave UDMA (Auto)
Each IDE channel supports a master device and a slave device. This mainboard supports
UltraDMA technology, which provides faster access to IDE devices. If you install a device
that supports UltraDMA, change the appropriate item on this list to Auto. You may have
to install the UltraDMA driver supplied with this mainboard in order to use an UltraDMA
device.
fOnboard Device
Scroll to this item and press <Enter> to view the following screen:
f
Phoenix-AwardBIOS CMOS Setup Utility
Onboard Device
Item Help
Menu Level
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
AC97 AUDIO [Auto]
Onboard LAN Device [Enabled]
Onboard LAN Boot ROM [Disabled]
Onboard 1394 Device [Enabled]
f
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
USB Controller (Enabled)
This item enables the USB controller. Leave this at the default “Enabled” if you want to
connect USB devices to your computer.
USB 2.0 Controller (Enabled)
Enable this item if want to use the USB 2.0.
ATA 66/100 Cable Msg (Enabled)
This item enalbes or disabled the display of the ATA 66/100 Cable Msg. If you install a
device that supports UDMA, change the appropriate item on this list to Auto. You may
have to install the UDMA driver supplied with this motherboard in order to use an UDMA
device.
Press <Esc> to return to the Integrated Peripherals screen.
SATA Mode (IDE)
Use this item to select the mode of the Serial ATA.
On-Chip Serial ATA (Disabled)
Enables or disables the built-in on-chip Serial ATA.
Serial ATA Port0/Port1 Mode (Primary Master)
Use this item to select the SATA0 master or SATA1 master.
To Next Page
