Page #47 background imageLoading...
Page #47 background image
41
Using BIOS
Integrated Peripherals
These options display items that define the operation of peripheral components on the
system’s input/output ports.
OnChip IDE Device [Press Enter]
Onboard Device [Press Enter]
SuperIO Device [Press Enter]
f
f
f
f
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals
Item Help
Menu Level
fOnChip IDE Device
Scroll to this item and press <Enter> to view the following screen:
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Phoenix-AwardBIOS CMOS Setup Utility
OnChip IDE Device
Item Help
Menu Level
ff
IDE HDD Block Mode [Enabled]
On-chip Primary PCI IDE [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
On-chip Secondary PCI IDE [Enabled]
IDE Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
IDE Secondary Master UDMA [Auto]
IDE Secondary Slave UDMA [Auto]
ATA 66/100 Cable Msg [Enabled]
*** On-Chip Serial ATA Setting***
SATA Mode [IDE]
On-chip Serial ATA [Disabled]
Serial ATA Port0 Mode [Primary Master]
Serial ATA Port1 Mode Primary Master
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
IDE HDD Block Mode (Enabled)
Block mode is also called block transfer, multiple commands, or multiple sector read/write.
If your IDE hard drive supports block mode (most new drives do), select Enabled for
automatic detection of the optimal number of block read/write per sector the drive can
support.
On-Chip Primary/Secondary PCI IDE (Enabled)
This integrated peripheral controller contains an IDE interface with support for two IDE
channels. Select Enabled to activate each channel seperately.
