ECS 915G-M5 - PNP;PCI Configurations

43
Using BIOS
PNP/PCI Configurations
This section describes configuring the PCI bus system. PCI (Peripheral Component Inter-
connect) is a system, which allows I/O devices to operate at speeds nearing CPU’s when they
communicate with own special components. All the options describes in this section are
important and technical and it is strongly recommended that only experienced users should
make any changes to the default settings.
Reset Configuration Data [Disabled]
Resources Controlled By [Auto(ESCD)]
IRQ Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
Assign IRQ For USB [Enabled]
INT Pin 1 Assignment [Auto]
INT Pin 2 Assignment [Auto]
INT Pin 3 Assignment [Auto]
INT Pin 4 Assignment [Auto]
INT Pin 5 Assignment [Auto]
INT Pin 6 Assignment [Auto]
INT Pin 7 Assignment [Auto]
INT Pin 8 Assignment [Auto]
Phoenix-AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Item Help
ff
Menu Level
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
x
Default is Disabled. Select
Enabled to reset Extended
System Configuration Data
(ESCD) when you exit Setup
if you have installed a new
add-on and the system
reconfiguration has caused
such a serious conflict that
the OS cannot boot
Init Display First [PCI Slot]
Reset Configuration Data (Disabled)
When you enable this item and restart the system, any Plug and Play configuration data
stored in the BIOS Setup is cleared from memory.
Resources Controlled By (Auto(ECSD))
You should leave this item at the default Auto(ESCD). Under this setting, the system
dynamically allocates resources to Plug and Play devices as they are required. If you cannot
get a legacy ISA (Industry Standard Architecture) expansion card to work properly, you
might be able to solve the problem by changing this item to Manual, and then opening up
the IRQ Resources submenu.
PCI/VGA Palette Snoop (Disabled)
This item is designed to overcome problems that can be caused by some non-standard VGA
cards. This board includes a built-in VGA system that does not require palette snooping so
you must leave this item disabled.
Assign IRQ For USB (Enabled)
“Enable” or “Disable” this item when users are to assign IRQ for the USB interface onboard.
In the IRQ Resources submenu, if you assign an IRQ to Legacy ISA, then that
Interrupt Request Line is reserved for a legacy ISA expansion card. Press
<Esc> to close the IRQ Resources submenu.
•
Init Display First (PCI Slot)
Use this item to specify the initial display to be the PCI slot or the graphics chip integrated
on the motherboard.
