PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the param-
eters for critical voltages, critical temperatures, and fan speeds.
f
Case Open Warning [Disabled]
Case has been CLOSING
Shutdown Temperature [Disabled]
Current System Temperature
Current CPU1 Temperature
NBFAN1
CPU FAN
CAS FAN
CPU Vcore
1.50 V
3.30 V
Smart CPUFan Function [Disabled]
CPUFan Tolerance Value 5
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
Item Help
Menu Level
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Shutdown Temperature (Disabled)
Enables you to set the maximum temperature the system can reach before powering down.
System Component Characteristics
These items allow end users and technicians to monitor data provided by the BIOS on this
motherboard. You cannot make changes to these fields.
• Current CPU/System Temperature
• NB FAN Speed
• CPU Fan Speed
• CAS FAN Speed
• CPU Vcore
• 1.5V
• 3.3V
Case Open Warning (Disabled)
This item enables or disabled the warning if the case is opened up, and the item below
indicates the current status of the case.
INT Pin1~8 Assignment (Enabled)
Identifies the interrupt request (IRQ) line assigned to a device connected to the PCI inter-
face of your system.
X
Smart CPUFan Function (Disabled)
This item enables users to set to which Celsius degree when the Smart Fan2 start function-
ing. The default value is 40 to 104 Celsius degree.
CPUFan Tolerance Value (5)
This item helps you to adjust the frequency of Smart Fan.
