Using BIOS
Serial Port A (Auto)
The item is used to assign the I/O address and interrupt request (IRQ) for onboard serial
port 1 (COM1)
Parallel Port Mode (ECP)
Use this item to set the parallel port mode. You can select Normal (Standard Parallel
Port),ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or EPP & ECP.
Azalia (Auto)
Press <Esc> to return to the Advanced Features page.
Press <Esc> to return to the Advanced Features page.
This option allows you to control the onboard Azalia audio. Disable this item if you are
going to install a PCI audio add-on card.
IDE Controller (Enabled)
Use this item to enable or disable either or both of the onboard Primary and Secondary IDE
channels.
SATA Configure as (IDE)
Use this item to define the controller type of the SATA device, whether to be the IDE
Controller or RAID controller.
Channel 1/2/3/4 Master/Slave
Your computer has four IDE channels and each channel can be installed with one or
twodevices (Master and Slave). In addition, this motherboard supports four SATA channels
andeach channel allows one SATA device to be installed. Use these items to configure
eachdevice on the IDE channel.
Compatible (Enhanced Non-AHCI)
When this item sets to Compatible mode, SATA and. PATA drives are auto-detected. and
placed in Legacy mode. If it set to Enhanced (non-AHCI) mode, SATA and PATA drives
are auto-detected and placed in. Native IDE mode.
IDE Configuration
IDE Controller <Enabled>
SATA Configure as <IDE>
Compatible <Enhanced Non-AHCI>
Channel 1 Master [Not Installed ]
Channel 1 Slave [Not Installed ]
Channel 2 Master [Not Installed ]
Channel 2 Slave [Not Installed ]
Channel 3 Master [Not Installed ]
Channel 3 Slave [Not Installed ]
Channel 4 Master [Not Installed ]
Channel 4 Slave [Not Installed ]
Main Advanced Power Security Boot Exit
f
f
f
f
f
f
f
f
f IDE Configuration (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
DISABLED: disables both
the PATA & SATA IDE
controllers. BOTH:
enables both the PATA &
SATA IDE controllers.
f
Select Boot Device
Selecct Screen
Select Item
Select SubMenu
Setup Defaults
Save and Exit
Exit
mn
Enter
F9 =
F10 =
Esc =
-
<>
InsydeH2O Setup Utility
Infrared Port (Disabled)
The item is used to disable or enable the infrared port.
Onboard LAN Device (Enabled)
Use this item to enable or disable the Onboard LAN Device.
