38
Using BIOS
Main
Advanced
Security
Power
Boot
Exit
Onboard LAN Boot ROM
<Disabled>
Boot
This option defines advanced information about your system.
Onboard LAN Boot ROM (Disabled)
This item allows you to enable or disable the onboard LAN Boot ROM function.
Disables or enables PXE
boot to LAN.
f
Select Boot Device
Selecct Screen
Select Item
Select SubMenu
Setup Defaults
Save and Exit
Exit
mn
Enter
F9 =
F10 =
Esc =
+ -
<>
InsydeH2O Setup Utility
43
45
Table of Contents
Default Chapter
5
Table of Contents
5
Chapter 1 Introducing the Motherboard
7
Introduction
7
Feature
8
Motherboard Components
10
Chapter 2 Installing the Motherboard
13
Safety Precautions
13
Choosing a Computer Case
13
Installing the Motherboard in a Case
13
Checking Jumper Settings
14
Setting Jumpers
14
Checking Jumper Settings
15
Jumper Settings
15
Connecting Case Components
16
Front Panel Header
18
Installing Hardware
19
Installing the Processor
19
Installing Memory Modules
21
Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive
23
Installing a Floppy Diskette Drive
24
Installing Add-On Cards
25
Connecting Optional Devices
27
Connecting I/O Devices
30
Chapter 3 Using BIOS
31
About the Setup Utility
31
Entering the Setup Utility
31
Updating the BIOS
32
Using BIOS
32
Main Features
33
Advanced Features
34
PCI Configuration
34
Boot Configuration
35
Peripheral Configuration
35
IDE Configuration
36
Video Configuration
37
USB Configuration
37
Chipset Configuration
38
ACPI Table / Features Control
39
System Health
40
Security Features
41
Power Features
42
Boot
44
Exit
45
Chapter 4 Using the Motherboard Software
47
About the Software CD-ROM
47
Auto-Installing under Windows 2000/XP
47
Running Setup
48
Manual Installation
50
Utility Software Reference
