Page #39 background imageLoading...
Page #39 background image
33
Using BIOS
f
ACPI Table / Features Control
APIC - IO APIC Mode <Enabled>
Spread Spectrum <Enabled>
Main Advanced Power Security Boot Exit
ACPI Table/Featurees Control (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
f
Select Boot Device
Selecct Screen
Select Item
Select SubMenu
Setup Defaults
Save and Exit
Exit
mn
Enter
F9 =
F10 =
Esc =
-
<>
InsydeH2O Setup Utility
APIC - IO APIC Mode (Enabled)
Use this item to enable or disable the the APIC (Advanced Programmable Interrupt Con-
troller) mode. APIC provides symmetric multi-processing (SMP) for systems, allowing
support for up to 60 processors.
Spread Spectrum (Enabled)
If you enable this item, it can significantly reduce the EMI (Electro-Magnetic Interference)
generated by the system.
This item is valid only for
WIN2K and WINXP. Also, a
fresh install of the OS must
occur when APIC Mode is
desirred. Test the IO ACPI by
setting item to Enable. The
APIC Table will then be pointed
to by the RSDT, the Local APIC
will be initialized, and the
Press <Esc> to return to the Advanced Features page.
