3
Introducing the Motherboard
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memroy timing
Some hardware specifications and software items are subject to change with-
out prior notice.
BIOS Firmware
This motherboard uses Insyde BIOS that enables users to configure many system
features including the following:
The firmware can also be used to set parameters for different processor clock speeds.
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• One VGA port
• Four USB ports
• One LAN port (optional)
• Audio jacks for microphone, line-in and line-out
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
The motherboard supports UltraDMA bus mastering with transfer rates of 100/66 MB/s.
The motherboard comes with the following expansion options:
Expansion Options
• One PCI Express x16 slot for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One 40-pin IDE low profile header that support two IDE devices
• One floppy disk drive interface
• Four 7-pin SATA connectors
• Two-Wire Serial Interface (TWSI) for VPD EEPROM
• Compliant wtih PCI Express base specification 1.1a
• Compliant to 802.3x flow control
• Supports IEEE 802.1p and 802.1q
• Compliant with 10/100 IEEE 802.3
• Support WOL power management and ACPI 2.0 specification
Onboard LAN (Optional)
This motherboard may support either of the following LAN chipset:
• Two-Wire Serial Interface (TWSI) for VPD
• Compliant wtih PCI Express base specification 1.1
• Compliant to 802.3x flow control
• Supports IEEE 802.3u/ab, 802.1p and 802.1q
• Compliant with 10/100/1000 IEEE 802.3
• Support WOL power management and ACPI 2.0 specification
