B250H4-M20 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1151 socket for Intel
®
Kabylake/Skylake processor
2. CPU_FAN 4-pin CPU cooling fan connector
3. DIMM_1~2 288-pin DDR4 Module slots
4. ATX_POWER Standard 24-pin ATX power connector
5. F_PANEL Front panel switch/LED header
6. CASE Case open header
7. SATA1~4 Serial ATA 6.0 Gb/s connectors
8. BZ Buzzer header
9. F_USB1~2 10-pin Front Panel USB 2.0 headers
10. USB3F Front Panel USB 3.0 header
11. COM Onboard serial port header
12. F_AUDIO Front panel audio header
13. PCIEX1_1 PCI Express x1 Gen3 slot
14. CLR_CMOS Clear CMOS jumper
15. BT Battery
16. PCIEX16 PCI Express x16 Gen3 slot for graphics interface
17. M2 2242/2260/2280 supports PCI-E Gen 3 x 4 SSD & Intel®
Optane
TM
Technology
18. SYS_FAN 4-pin System cooling fan connector
19. ATX_12V 4-pin +12V power connector
