ECS B75H2-M3 User Manual

Chapter 3
B75H2-M3 USER MANUAL
49
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
CPU OverClocking
Configuration
Main Advanced Chipset M.I.B III Boot Security Exit
M.I.B III (MB Intelligent BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology Enabled
Intel(R) Core(TM) i3-3220 CPU @ 3.30GHz
Processor Speed 3300 MHz
Memory Frequency 1333 MHz
Total Memory 2048MB (DDR3 )
CPU Current Voltage 1.068V
VTT Current Voltage 1.044V
DIMM Current Voltage 1.500V
CPU OverClocking Configuration
Scroll to this item to view the following screen:
CPU Ratio (99)
This item allows users to control non turbo CPU ratio.
CPU Frequency (1/100 MHz) (10000)
This item shows the information of CPU Frequency.
Main Advanced Chipset M.I.B III Boot Security Exit
Enhanced Intel Speedstep
Technology
CPU OverClocking Configuration
CPU Frequency (1/100 MHz) 10000
CPU Ratio 99
Enhanced Intel SpeedStep Technology Enabled
RuntimeTurbo Enable Disabled
Over Clocking Extra Vol. (1/256 V) 0
IA Core Current Max (1/8 Amp) 896
iGFX Core Current Max (1/8 Amp) 400
Long Duration Maintained 28
+/- : Change Opt.
Enter/Dbl Click : Select

: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit

+/- : Change Opt.
Enter/Dbl Click : Select

: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit


ECS B75H2-M3 Specifications

General

Internal memory	16 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Power fan connector	Yes
Number of COM connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA
On-board graphics card	No
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	210 mm
Width	244 mm
