Installing the Motherboard

Refer to the illustration below for proper installation:

1 Attach either cable end to the connector on the motherboard.

2 Attach the other cable end to the SATA hard drive.

3 Attach the SATA power cable to the SATA hard drive and connect the

other end to the power supply.

SATA cable (optional)

SATA power cable (optional)

Questions and Answers:

Need help?

Do you have a question about the ECS G41T-R3 and is the answer not in the manual?

ECS G41T-R3 Specifications

General

Form Factor	Micro ATX
CPU Socket	LGA 775
Memory Type	DDR3
Memory Slots	2
Maximum Memory	8 GB
Graphics	Integrated Intel GMA X4500
Storage Interface	4 x SATA 3Gb/s
IDE Ports	1 x IDE
Video Outputs	1 x VGA
Audio	Realtek ALC662 6-Channel HD Audio
Chipset	Intel G41
Expansion Slots	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
