ECS GF8200A User Manual

40
Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Smart Fan Function Press Enter
ShutDown Temperature Disabled
Vcore : 1.224V
VDIMM : 1.840V
VNB : 1.064V
VHT : 1.184V
CPU FAN Speed : 1962 RPM
SYS FAN Speed : 0 RPM
CPU Temperature : 40°C/82°F
System Temperature : 34°C/93°F
Help Item
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
PC Health Status
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Smart Fan Function
Help Item
CPU SMART FAN Control Disabled
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
Disabled
Enabled
Options
f
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default settings
F1: General Help
mn
< >
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default settings
F1: General Help
mn
< >
Hardware Health Event Monitoring
CPU SMART FAN Control (Disabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the CPU temperature.
Press <Esc> to return to the PC Health Status page.

ECS GF8200A Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Compatible processor series	AMD Sempron
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	5
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Audio chip	IDT 92HD206
Audio output channels	7.1 channels
Motherboard form factor	ATX
BIOS type	AMI
BIOS memory size	64 Mbit
PCI Express x1 slots	2
Maximum graphics card memory	512 MB
RAID levels	0, 1
