ECS GF8200A

1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the GF8200A motherboard. This motherboard is a high
performance, enhanced function motherboard that supports socket for
AMD
Phenom
TM
processor (socket AM2+)/AMD Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/
Sempron
TM
processors for high-end business or personal desktop markets.
This motherboard is based on NVIDIA
®
GeForce8200 (MCP78S) Premium media and
communications processor (MCP) for best desktop platform solution. GeForce8200
is a single-chip, highly integrated, high performance HyperTransport peripheral
controller, unmatched by any other single chip-device controller. The memory con-
troller supports DDR2 memory DIMM frequencies of 1066*
1
(AM2+)/800/667/533/
400. It supports four DDR2 sockets with maximum memory size of 32 GB*
2
. High
resolution graphics via one PCI Express x16 slot, two PCI Express x1 slots, 12 USB
2.0 ports (6 USB ports and 3 USB 2.0 headers support additional 6 USB ports) and
SATA support with RAID function.
There is an advanced full set of I/O ports in the rear panel, including PS/2 mouse and
keyboard connectors, one VGA port, one HDMI port, one eSATA port, six USB
ports, one LAN port and audio jacks for microphone, line-in and 6/8-ch (optional)
line-out. This motherboard is designed in an ATX form factor using a four-layer
printed circuit board and measures 305 mm x 220 mm.
2. Due to the DRAM maximum size (2 GB per dimm) at present, the
memory maximum size we have tested is 8 GB.
1. Due to the limitation of AMD CPU spec, please refer to Memory QVL
for more information.
*
