ECS GF8200A User Manual

43
Using BIOS
When using black-boxed CPU, the following screen appears.
CMOS Setup Utility - Copyright (C) 1985-2007 American Megatrends, Inc.
M.I.B (MB Intelligent BIOS)
Help item
AMD Athlon (tm) 64 X2 Dual Core Processor 5000+
Revision : G2
Cache L1 : 256KB
Cache L2 : 1024KB
Cache L3 : N/A
Speed : 2615MHz, NB CLK : N/A
Current FSB Multiplier : 13x
Maximum FSB Multiplier : 25x
Auto Detect DIMM/PCI Clk Enabled
CPU/LDT Spread Spectrum Enabled
PCI Spread Spectrum Enabled
CPU Frequency, MHz 200
AMD CPU Function: Press Enter
DRAM Frequency Auto
DRAM Timing Mode Auto
CPU Voltage Disabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
f
f
123
1
2
3
1
2
3
1
2
3
1
2
3
123
f
Configure CPU
frequency
fAMD CPU Function:(Press Enter)
Scroll to this item and press <Enter> to view the following screen:
AMD Overclock Ctrl: Disabled
Help Item
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
AMD CPU Function:
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default settings
F1: General Help
mn
< >
Press <Esc> to return to the main menu setting page.

ECS GF8200A Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Compatible processor series	AMD Sempron
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	5
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Audio chip	IDT 92HD206
Audio output channels	7.1 channels
Motherboard form factor	ATX
BIOS type	AMI
BIOS memory size	64 Mbit
PCI Express x1 slots	2
Maximum graphics card memory	512 MB
RAID levels	0, 1
