ECS GF8200A User Manual

3
Introducing the Motherboard
This motherboard supports Ultra DMA bus mastering with transfer rates of 133/
100/66/33 Mb/s.
:
• One PCI Express x16 slot for Graphics Interface
• Two PCI Express x1 slots
• Three 32-bit PCI v2.3 compliant slots
• One IDE connector supporting up to two IDE devices
• One floppy disk drive interface
• Five 7-pin SATA connectors
Expansion Options
The motherboard comes with the following expansion options:
Onboard LAN (Optional)
The onboard LAN provides either of the following features:
Audio (Optional)
The onboard Audio provides either of the following features:
• 5.1 Channel High Definition Audio Codec
• DACs Support 96K/48K/44.1KHz DAC sample rate
• Power support: Digital:3.3V; Analog:5.0V
• WOW
TM
and Tru Surround
TM
from SRS
• Provides single ended CD input with DRM solutions and legacy
OS issues
• 7.1 Channel High Definition Audio Codec
• SPDIF In/Out supports 96K/48K/44.1KHz plus SPDIF OUT sup-
ports 88.2 KHz
• Power support: Digital:3.3V; Analog:5.0V
• MAxx Player
TM
from Waves
• Provides single ended CD input with DRM solutions and legacy
OS issues
• Integrated Gigabit Ethernet Controller for PCI Express
TM
Applications
• Integrated 10/100/1000 transceiver
• Wake-On-LAN and remote wake-up support
• Integrated Fast Ethernet Controller for PCI Express
TM
Applications
• Integrated 10/100 transceiver
• Wake-On-LAN and remote wake-up support

ECS GF8200A Specifications

General

Number of memory slots	4
Maximum internal memory	32 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Compatible processor series	AMD Sempron
USB 2.0 connectors	3
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	5
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Audio chip	IDT 92HD206
Audio output channels	7.1 channels
Motherboard form factor	ATX
BIOS type	AMI
BIOS memory size	64 Mbit
PCI Express x1 slots	2
Maximum graphics card memory	512 MB
RAID levels	0, 1
