H310CH5-TI2 USER MANUAL
2
QR Code for the complete manual download
on ECS website: http://www.ecs.com.tw
System BIOS
Form Factor
• Thin Mini ITX Size, 170mm x 170mm
• AMI BIOS with 64Mb SPI Flash ROM
- Supports recovery
- Supports Dual/Triple Display
- Supports Plug and Play
- Supports ACPI & DMI
- Supports STR (S3) /STD (S4)
- Supports Hardware monitor
- Audio and LAN can be disabled in BIOS
- F7 hot key for boot up devices option
• 1 x Consumer infrared header (CIR)
• 1 x Digital microphone header (For All-In-One Specification)
• 1 x LVDS connetor (For All-In-One Specification)
• 1 x LVDS brightness switch header (For All-In-One
Specification)
• 1 x LCD panel select jumper (For All-In-One Specification)
