H310CH5-TI2 USER MANUAL
1
Brief Introduction
Specifications
CPU
• Dual channel memory architecture
• 2 x DDR4 SO-DIMM sockets support up to 32 GB
• Supports DDR4 2666/2400 MHz SDRAM
Memory
• 2 x M.2 slots
- 1 x M.2 socket (Key E) type 2230 supports Wifi (PCIe Gen.2) /
BT
- 1 x M.2 socket (Key M) type 2260/2280 supports SSD (SATA/
PCIe Gen.2)
• Supported by Intel
®
H310 Express Chipset
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit LAN
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Realtek ALC662-VD0-GR
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
• LGA1151 socket for Intel
®
Coffee Lake processor
• Supports CPU up to 65W
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 1 x 8-pin USB 2.0 header (black) supports card reader and cam-
era or other USB2.0 device
• 1 x 5-pin USB 2.0 header (yellow) supports touch panel or other
2.0 device
• 2 x Serial ATA 6Gb/s connectors
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x COM header
• 1 x Case open header
• 1 x TPM header
• 1 x Amplifier Speaker header
• 1 x SATA power connector
Internal I/O
Connectors &
Headers
Note: Please go to our website for the latest CPU support list.
Note: Please go to our website for the latest Memory support list.
• 1 x 19V DC_IN port
• 1 x D-sub (VGA) port
• 1 x HDMI port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 2 x Audio ports (1 x line-out, 1 x Microphone)
Chipset
• Intel
®
H310 Chipset
