H310CH5-TI2 USER MANUAL
4
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1151 socket for Intel® Coffee Lake Processor
2. M2_2 (Key-M) type 2260/2280 supports SSD (SATA/PCIe Gen.2)
3. CLR_CMOS Clear CMOS jumper
4. M2_1 (Key-E) type 2230 supports Wifi (PCIe Gen.2) / BT
5. SPKR 2 Channels audio speaker header (For All-In-One Specification)
6. DMIC Digital microphone header (For All-In-One Specification)
7. F_AUDIO Front panel audio header
8. BT Battery
9. CASE Case open header
10. DIMM1~2 DDR4 SO-DIMM socket
11. SATA_PWR SATA power connector
12. USB_CR_CAM USB 2.0 header (black) supports card reader and camera or other USB 2.0 device
13. USB_TP USB 2.0 header (yellow) supports touch panel or other USB 2.0 device
14. USB3F Front panel USB 3.0 header
15. SATA3_1~2 Serial ATA 6Gb/s connectors
16. SYS_FAN 4-pin system cooling fan connector with smart fan function
17. CPU_FAN 4-pin CPU cooling fan connector with smart fan function
18. COM Onboard serial port header
19. F_PANEL Front panel switch/LED header
20. CIR Consumer infrared header
21. LVDS LVDS connector (For All-In-One Specification)
22. MON_SW LVDS brightness switch header (For All-In-One Specification)
23. DISP_BRT LVDS brightness control header (For All-In-One Specification)
24. LCD_SEL LCD panel select jumper (For All-In-One Specification)
25. TPM Trusted platform module header
