ECS H61H2-A User Manual

Using BIOS
53
This page enables you to set the keyboard NumLock state.
Boot Menu
Bootup NumLock State (On)
This item enables you to select NumLock state.
1st/2nd/3rd/4th/5th/6th/7ht/8th Boot
These items set the system boot order.
Hard Disk Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drives.
CD/DVD ROM Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD ROM drives.
USB/Floppy Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB/floppy drives.
USB HardDisk Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB harddisk drives.
USB Flash Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB flash drives.
USB CD/DVD ROM Drive Priorities (Press Enter)
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD ROM drives.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Specifies the Boot Device
Priority sequence from
available Hard Drives.
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Boot Configuration
Bootup NumLock State
On
Set Boot Priority
1st Boot
Hard Disk
2nd Boot CD/DVD
3rd Boot USB/Floppy
4th Boot USB CD/DVD
5th Boot USB Hard Disk
6th Boot USB Flash
7th Boot Network
8th Boot UEFI
Hard Disk Drive Priorities [Press Enter]
CD/DVD ROM Drive Priorities [Press Enter]
USB/Floppy Drive Priorities [Press Enter]
USB CD/DVD ROM Drive Priorities [Press Enter]
USB HardDisk Drive Priorities [Press Enter]
USB Flash Drive Priorities [Press Enter]
Network Device Priorities [Press Enter]
UEFI Boot Drive Priorities [Press Enter]

ECS H61H2-A Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Component for	PC
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express x1 slots	3
LAN controller	Realtek RTL8111E
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
ACPI version	3.0
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	195 mm
Width	305 mm
