Introducing the Motherboard

• LGA1155 socket for latest Intel

Core

Family/Pentium

Celeron

processors

• DMI 5.0GT/s

• Supports “Hyper-Threading” technology CPU

CPU

Specifications

• Intel

H61 Chipset

Chipset

• ITE IT8893 PCI Bridge supports two PCI slots expansion

Extra Chips

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin 12V Power connector

• 1 x Speaker header

• 1 x Front panel switch/LED header

• 1 x Front Panel audio header

• 1 x S/PDIF out header

• 1 x CLR_CMOS header

• 1 x Serial port header (COM)

• 1 x Parallel port header (LPT)

• 4 x SATA II 3Gb/s connectors

• 2 x USB2.0 headers support additional four USB 2.0 ports

(F_USB2 supports EZ Charger)

• 1 x ME UNLOCK header

• 1 x Chassis intrusion header

• 1 x 4-pin CPU_FAN connector

• 1 x 3-pin SYS_FAN connector

• 1 x 3-pin PWR_FAN connector

• Dual-channel DDR3 memory architecture

• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB

• Supports DDR3 1333/1066

• 1 x PCI Express x16 slot

• 3 x PCI Express x1 slots

• 2 x PCI slots

• Supported by Intel

H61 Chipsets

- 4 x SATA 3.0 Gb/s Host Controllers

Memory

Expansion

Slots

Storage

• Realtek ALC662 6-Ch High Definition audio CODEC

• Compliant with HD audio specification

• 1 x PS/2 keyboard & PS/2 mouse connectors

• 1 x D-sub port

• 1 x DVI port (optional)

• 1 x RJ-45 port

• 1 x Audio port (Line in, Microphone in, Line out)

• 4 x USB 2.0 ports & 2 ports (optional)

Audio

LAN

Internal I/O

Connectors &

Headers

• AMI BIOS with 64 Mb SPI Flash ROM

• Supports Plug and Play, STR(S3)/STD(S4), Hardware moni-

tor, Multi Boot

System BIOS

Rear Panel I/O

• Realteck 8111E Gigabit Fast Ethernet (Co-lay 10/100)

Other manuals for ECS H61H2-A

Manual88 pages

Questions and Answers:

Need help?

Do you have a question about the ECS H61H2-A and is the answer not in the manual?

ECS H61H2-A Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Component for	PC
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express x1 slots	3
LAN controller	Realtek RTL8111E
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
ACPI version	3.0
BIOS memory size	32 Mbit
