ECS H61H2-M User Manual

6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for 2
nd
Generation Intel
®
Core
TM
Famil
y
Processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SATA1~2 Serial ATA 3.0 Gb/s connectors
6. SPI_DEBUG SPI debug header-for factory use only
7. SPK Speaker header
8. COM Onboard serial port header
9. SATA3~4 Serial ATA 3.0 Gb/s connectors
10. F_PANEL Front panel switch/LED header
11. F_USB1~2 Front panel USB 2.0 header (F_USB1 supports EZ Charger)
12. CASE CASE open header
13. ME_UNLOCK ME unlock header-for factory use only
14. F_1394A Front 1394 header (Optional)
15. TPM Trusted Platform Module header
16. LPT Printer Header
17. CLR_CMOS Clear CMOS jumper
18. SYS_FAN 3-pin system cooling fan connector
19. SPDIFO SPDIF out header
20. F_AUDIO Front panel audio header
21. PCI1~2 32-bit add-on card slots
22. PCIE1 PCI Express x1 slot
23. PCIEX16 PCI Express slot for graphics interface
24. ATX12V 4-pin +12V power connector
1. CPU Socket

ECS H61H2-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
USB 2.0 connectors	2
Power fan connector	Yes
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
LAN controller	Atheros AR8151
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	220 mm
Width	244 mm
