3
Introducing the Motherboard
The motherboard comes with the following expansion options:
• One PCI Express x16 slot for Graphic Interface
• One PCI Express x1 slot
• Four SATA 3.0 Gb/s connectors
Expansion Options
The motherboard has a full set of I/O ports and connectors:
Integrated I/O
• One PS/2 keyboard and PS/2 mouse connectors
• One D-sub (VGA) port
• One DVI port (Co-Lay HDMI Port)
• Four USB 2.0 ports
• One RJ45 LAN connector
• Two USB 3.0 ports (USB 2.0 optional)
• Audio jacks 6-ch for microphone, line-in and line-out
The firmware can also be used to set parameters for different processor clock
speeds.
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
• Graphic parameters
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be operated
in the ambiance between 0 and 50 °C.
1394a Firewire (Optional)
• Compliant with single chip host controller for IEEE Std 1394-1955 and
IEEE 1394a-2000
• Integrated 400 Mb/s 2-Port PHY for the PCI BUS
• 3.3V Power Supply with 5V Tolerant Inputs
