Introducing the Motherboard

• LGA1155 socket for latest 2

Generation Intel

Core

Fam-

ily processors

• Supports “Hyper-Threading” technology CPU

CPU

Specifications

• Intel

H61 Chipset

Chipset

• Dual-channel DDR3 memory architecture

• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB

• Supports 1333/1066 DDR3 SDRAM

• 1 x PCI Express x16 Gen2 slot

• 1 x PCI Express x1 Gen2 slot

• 2 x PCI slots

• Supported by Intel

H61 Express Chipset

-4 x Serial ATA 3.0 Gb/s devices

• VIA VT1705 6-Ch HD audio CODEC

• Compliant with HD audio specification

• 1 x PS/2 keyboard and PS/2 mouse connectors

• 1 x D-sub (VGA) port

• 1 x DVI port (Co-Lay HDMI Port)

• 4 x USB 2.0 ports

• 1 x RJ45 LAN connector

• 2 x USB 3.0 ports (USB 2.0 optional)

• Audio jacks 6-ch for microphone, line-in and line-out

Memory

Expansion

Slots

Storage

LAN

Rear Panel I/O

• Atheros AR8151 Gigabit Lan (Co-lay Atheros AR8152 10/

100 LAN)

Audio

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin 12V Power connector

• 1 x 4-pin CPU_FAN connector

• 1 x 3-pin SYS_FAN connector

• 1 x Frant Panel audio header

• 1 x Frant Panel switch/LED header

• 1 x Speaker header

• 1 x SPDIF out header

• 4 x Serial SATA 3Gb/s connectors

• 1 x 1394 header (Optional)

• 2 x USB 2.0 headers support additional four USB 2.0 ports

(F_USB1 support EZ charger)

• 1 x Chassis intrusion header

• 1 x TPM header

• 1 x Serial port header(COM)

• 1 x Parallel port header(LPT)

• 1 x CLR_CMOS header

Internal I/O

Connectors &

Headers
