ECS H61H2-M User Manual

19
Installing the Motherboard
LPT: Onboard parallel port Header
This is a header that can be used to connect to the printer, scanner or other devices.
1 STROBE 14 AFD
2 PD0 15 ERROR
3 PD1 16 INIT
4 PD2 17 SLCT
5 PD3 18 Ground
6 PD4 19 Ground
7 PD5 20 Ground
8 PD6 21 Ground
9 PD7 22 Ground
10 ACK 23 Ground
Pin Signal Name Pin Signal Name
11 BUSK 24 Ground
12 PE 25 Ground
13 SLCT 26 Key
TPM(Optional): Trusted Platform Module header
Trusted platform module (TPM) is a published specification detailing a
microcontrollerthat can store secured information, and implementations of that
specification.
1 TPM_CLK 11 LAD0
2 GND 12 GND
3 LFRAME# 13 RESERVE0
4 KEY 14 RESERVE1
5 LREST# 15 VCC3_DUAL
6 SMBDATA 16 SERIRQ
7 LAD3 17 GND
8 LAD2 18 GND
9 VCC3 19 LPCPD#
10 LAD1 20 SMBCLK
Pin Signal Name Pin Signal Name

ECS H61H2-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
USB 2.0 connectors	2
Power fan connector	Yes
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
LAN controller	Atheros AR8151
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	220 mm
Width	244 mm
