ECS H61H2-M User Manual

52
Using BIOS
RAS# to CAS# Delay(tRD) (7)
This item specifies the RAS# to CAS# delay to Rd/Wr command to the same bank.
RAS# Active Time(tRAS) (20)
This item specifies the RAS# active time.
GT OverClocking (Disabled)
This item allows you to control the internal GFX Turbo mode.
Press <Esc> to return to the Performance Tunning page.
Press <Esc> to return to the M.I.B III menu page.
Row Precharge Time(tRP) (7)
This item specifies Row precharge to Active or Auto-Refresh of the same bank.
Memory Timing Configuration
This item shows the information of Memory Timing Configuration.
CAS#Latency(tcl) (7)
This item determines the operation of DDR SDRAM memory CAS(colulmn address
strobe). It is recommanded that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
Intel Graphics Configuration
This item shows the information of Intel Graphics Configutation.

ECS H61H2-M Specifications

General

Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
USB 2.0 connectors	2
Power fan connector	Yes
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
LAN controller	Atheros AR8151
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	220 mm
Width	244 mm
