H61H2-M16 USER MANUAL
Chapter 3
CPU OverClocking Configuration
Scroll to this item to view the following screen:
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
Enhance Intel SpeedStep
Technology
F4: Save & Exit
CPU Ratio (35)
This item allows users to control non turbo CPU ratio.
CPU Frequency (100)
This item shows the information of the CPU frequency.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep Tech-
nology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Internal PLL OverVoltage (Disabled)
This item allows you to control the Internal PLL OverVoltage.
Runtime Turbo Enable (Disabled)
This item shows if CPU support runtime turbo or not.
Over Clocking Extra Vol.(1/256 V) (0)
Use this item to set over clocking extra voltage.
IA Core Current (Maximum)
Use this item to control CPU Current Limit.
iGFX Core Current (Maximum)
Use this item to control iGFX Core Current Limit.
Long Duration Power Limit Override (Maximum)
Intel(R) Turbo Boost Technology will use this power limit during the long duration
power limit time window.
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 35
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Internal PLL OverVoltage Disabled
Runtime Turbo Enable Disabled
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Power Maintianed 10
Short Duration Power Limit Override Maximum
Intel Graphics Configuration
Graphics Core Ratio Limit 23
Graphics Voltage(1/256) 0
