H61H2-M16 USER MANUAL
51
Chapter 3
Main Advanced Chipset M.I.B III Boot Security Save & Exit
CPU OverClocking Configuration
Scroll to this item to view the following screen:
Enhanced Intel SpeedStep
Technology
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 35
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
Internal PLL OverVoltage [Disabled]
Runtime Turbo Enable [Disabled]
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Power Maintianed 10
Short Duration Power Limit Override Maximum
Intel Graphics Configuration
Graphics Core Ratio Limit 23
Graphics Voltage(1/256) 0
CPU Ratio (35)
This item allows users to control non turbo CPU ratio.
CPU Frequency (100)
This item shows the information of the CPU frequency.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep Tech-
nology).
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Internal PLL OverVoltage (Disabled)
This item allows you to control the Internal PLL OverVoltage.
Runtime Turbo Enable (Disabled)
This item shows if CPU support runtime turbo or not.
Over Clocking Extra Vol.(1/256 V) (0)
Use this item to set over clocking extra voltage.
IA Core Current (Maximum)
Use this item to control CPU Current Limit.
iGFX Core Current (Maximum)
Use this item to control iGFX Core Current Limit.
Long Duration Power Limit Override (Maximum)
Intel(R) Turbo Boost Technology will use this power limit during the long duration
power limit time window.
