ECS H61H2-M2 Manual&Nbsp;

48
Using BIOS
Power Limit 2 Switch (Enabled)
Use this item to control the Power Limit 2. This is for Turbo mode.
Power Limit 1 Value(Watt) (65)
Use this item to control the limit of the TDP. This is for Turbo mode.
 Performance Tunning
Scroll to this item to view the following screen:
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
CPU Configuration
Performance Tuning
CPU Configuration
Chipset Configuration


CPU Configuration
Scroll to this item to view the following screen:
CPU Ratio (31)
This item allows users to control non turbo CPU ratio.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
IA Core Current
CPU Ratio 31
IA Core Current [Normal]
Power Limit 1 Value (Watt) 65
Power Limit 2 Switch [Enabled]
Power Limit 2 Value 81
Long duration Maintained 1
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
1 Core Ratio Limit 31
2 Core Ratio Limit 31
3 Core Ratio Limit 0
4 Core Ratio Limit 0
IA Core Current (Normal)
Use this item to control CPU Current Limit. This is for Turbo mode.

F1:General Help
+/- : Change Opt.
Enter : Select

:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit

F1:General Help
+/- : Change Opt.
Enter : Select

:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Main Advanced Chipset M.I.B III Boot Security Save & Exit

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
