49
Using BIOS
Power Limit 2 Value (81)
Use this item to control Power Limit 2. PL2 provides an upper limit of the TDP
excursions. This is for Turbo mode.
Long Duration maintainded (1)
Use this item to control the time window over PL1 value should be maintained. This
is for Turbo mode.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep
Technology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Press <Esc> to return to the Performance Tunning page.
Chipset Configuration
Scroll to this item to view the following screen:
Memory Multiplier Configuration
Memory Multiplier [10.67]
Memory Timing Configuration
CAS# Latency (tCL) 8
Row Precharge Time (tRP) 8
RAS# to CAS# Delay (tRCD) 8
RAS# Active Time (tRAS) 20
Intel Graphics Configuration
GT OverColocking [Enabled]
Graphics Current [Normal]
Graphics Core Ratio Limit 22
:Select Screen
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Disabled/Enabled GT
OverClocking
+/- : Value
Enter : Select
:Select Item
F1:General Help
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
1/2/3/4-Core Ratio (31/31/0/0)
This item shows the Core Ratio limit value.
Memory Multiplier Configuration
This item shows the information of Memory Multiplier Configuration.
Memory Multiplier (10.67)
This item determines the operation of DDR SDRAM memory CAS(colulmn address
strobe). It is recommanded that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
