Using BIOS

RAS# to CAS# Delay(tRD) (8)

This item specifies the RAS# to CAS# delay to Rd/Wr command to the same bank.

RAS# Active Time(tRAS) (20)

This item specifies the RAS# active time.

GT OverClocking (Disabled)

This item allows you to control the internal GFX Turbo mode.

Press <Esc> to return to the Performance Tunning page.

Press <Esc> to return to the M.I.B III menu page.

Row Precharge Time(tRP) (8)

This item specifies Row precharge to Active or Auto-Refresh of the same bank.

Memory Timing Configuration

This item shows the information of Memory Timing Configuration.

CAS#Latency(tcl) (8)

This item determines the operation of DDR SDRAM memory CAS(colulmn address

strobe). It is recommanded that you leave this item at the default value. The 2T

setting requires faster memory that specifically supports this mode.

Graphics Current (Normal)

This item shows the information of the Graphics Current.

Graphics Core Ratio Limit (22)

This item shows the information of the Graphics Core Ratio Limit.

Initate Graphics Adapter

This item shows the information of Intel Graphics Configutation.

Other manuals for ECS H61H2-M2

Need help?

Do you have a question about the ECS H61H2-M2 and is the answer not in the manual?

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II
