ECS H61H2-M2 User Manual

40
Using BIOS
f System Agent Configuration
Scroll to this item and press <Enter> and view the following screen:
The chipset menu items allow you to change the settings for the North Bridge
chipset, South Bridge chipset and other system.
Chipset Menu
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
System Agent (SA) Parameters
System Agent Configuration
PCH Configuration
f
f
f
ME Configuration
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Press <Esc> to return to the Chipset Menu page.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
System Agent Configuration
IGD Memory [64M]
DVMT Memory [256M]
IGD Multi-Monitor [Disabled]
Select DVMT 5.0 Pre-Allocated
(Fixed) Graphics Memory size
used by the Internal Graphics
Device.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics device) memory.
DVMT Memory (256M)
This item is used to select DVMT5.0 Total Graphic Memory size by the internal
Graphics Device.
IGD Multi-Monitor (Disabled)
This item enables or disables IGD (Internal Graphics device) multi-monitor.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
