ECS H61H2-M2 User Manual

51
Using BIOS
f CSM parameters
Scroll to this item and press <Enter> to view the following screen.
Launch CSM
Boot option filter
Launch PXE OpROM policy
This controls the execution of UEFI and Legacy PXE OpROM.
Launch Storage OpROM policy
This controls the execution of UEFI and Legacy Storage OpROM.
Launch Video OpROM policy
This controls the execution of UEFI and Legacy Video OpROM.
Other PCI device ROM priority
For PCI devices other than Network, Mass storage or Video defines which OpROM to
launch.
This option controls if CSM will be launched.
Press <Esc> to return to the Boot Menu page.
CSM parameters
OpROM execution, boot options filter,etc.
This option controls what devices system can boot to.
Hard Disk / CD/DVD ROM / USB Floppy / USB CD/DVD ROM / USB HardDisk /
USB Flash / Network Boot Drive Priorities
These items enable you to specify the sequence of loading the operating system.
Press <Enter> to see the submenu.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Launch CSM [Always]
Boot option filter [UEFI and Legacy]
Launch PXE OpROM policy [Do not launch]
Launch Storage OpROM policy [Legacy only]
Launch Video OpROM policy [Legacy only]
Other PCI device ROM priority [Legacy OpROM]
This option controls if CSM
will be launched
Main Advanced Chipset M.I.B III Boot Security Exit

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
