ECS H61H2-M2 User Manual

54
Using BIOS
f Key Management
Scroll to this item to view the following screen:
Platform Key (PK)
This item shows the information of the platform key.
Set PK/KEK/DB/DBX from File
This item launches the file browser to set Efi Variable from the file. The file data
must be formatted as Efi Variable with TimeBased Authenticated Header.
Get PK/KEK/DB/DBX to File
This item is used to store secure variable to a file with a matching name in selected
file system’s root.
Delete the PK/KEK/DB/DBX
This item is used to delete the variable.
Key Exchange Key Database (KEK)
This item shows the information of the key exchange key database.
Authorized Signature Database (DB)
This item shows the information of the authorized signature database.
Default Key Provisioning (Disabled)
This item enables or disables you to force OEM default secure boot keys if system is
in setup mode.
Append an entry to KEK/DB/DBX
This item launches the file browser to Append new signature database from the file.
The file data must be formatted as Efi Variable with TimeBased Authenticated Header.
Forbidden Signature Database (DBX)
This item shows the information of the forbidden signature database.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Force OEM default Secure
Boot Keys if System is in
Setup Mode.
Default Key Provisioning [Disabled]
Manage All Factory Keys (PK, KEK, DB, DBX)
Install default Secure Boot keys
Platform Key (PK) NOT INSTALLED
Set PK from File
Get PK to File
Delete the PK
Key Exchange Key Database (KEK) NOT INSTALLED
Set KEK from File
Get KEK to File
Delete the KEK
Append an entry to KEK
Authorized Signature Database (DB) NOT INSTALLED
Set DB from File
Get DB to File
Delete the DB
Append an entry to DB
Forbidden Signature Database (DBX) NOT INSTALLED
Set DBX from File
Get DBX to File
Delete the DBX
Append an entry to DBX
f
f
f
f
f
f
f
f
f
f
f
f
f
f
f
Main Advanced Chipset M.I.B III Boot Security Exit

ECS H61H2-M2 Specifications

General

Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Certification	RoHS
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7 32-bit/64-bit
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit
Supported storage drive interfaces	SATA II

Weight and Dimensions

Depth	180 mm
Width	225 mm
