Press <Esc> to return to the M.I.B III Menu page.
CPU Ratio (22)
This item allows users to control non turbo CPU ratio.
IA Core Current Max (Maximum)
Use this item to control CPU Current Limit.
iGFX Core Current (Maximum)
Use this item to control iGFX Core Current Limit.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep Tech-
nology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Intel(R) Turbo Boost Technology will use this power limit during the Long Duration
Power Limit Time Window.
Long Duration Maintained (10)
Use this item to control the time window over PL1 Value should be maintained. This
is for Turbo Mode.
Intel(R) Turbo Boost Technology will use this power limit for a very short duration.
After that, the Long Duration Power Limit will be honored.
1/2/3/4 Core Ratio Limit (39/38/37/36)
This item shows the Core Ratio Limit Value.
Long Duration Power Limit Override (Maximum)
Short Duration Power Limit Override (Maximum)
Runtime Turbo Enable (Disabled)
This item shows if CPU support Runtime Turbo.
Internal PLL OverVoltage (Disabled)
This item allows you to control the Internal PLL OverVoltage.
Over Clocking Extra Vol. (1/256 V) (0)
This item allows you to control Extra CPU Voltage.
Graphics Core Ratio Limit (18)
This item allows you to control the internal GFX Turbo ratio.
Graphics Voltage (1/256) (0)
This item allows you to adjust the internal GFX voltage.
