Using BIOS
Press <Esc> to return to the M.I.B III menu page.
ICC Enable (Disabled)
This item allows you to enable or disable current ICC.
Current ICC Profiles Index (N/A)
This item shows current ICC profiles index.
 Performance Tunning
Scroll to this item to view the following screen:
CPU Configuration
Chipset Configuration

:Select Screen
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
CPU Configuration
+/- : Change Opt.
Enter : Select

:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit


CPU Configuration
Scroll to this item to view the following screen:
+/- : Change Opt.
Enter : Select


:Select Screen
:Select Item
CPU Ratio
IA Core Current [Nomal]
Power Limit 1 Value (Watt) 95
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Non Turbo Ratio Override
Power Limit 2 Switch [Enabled]
Power Limit 2 Value 118
Long duration maintained 1
Enhanced Intel SpeedStep Technolog [Enabled]
Turbo Mode [Enabled]
1 Core Ratio Limit 37
2 Core Ratio Limit 36
3 Core Ratio Limit 35
4 Core Ratio Limit 34
Main Advanced Chipset M.I.B III Boot Security Save & Exit
33
