This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for new 2nd Generation Intel?CoreTM
Family/Pentium/Celeron processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SATA1~2 Serial ATA connectors (Support SATA 6Gb/s)
6. SPI_DEBUG SPI debug header-for factory use only
7. SATA3~6 Serial ATA connectors (Support SATA 3Gb/s)
8. F_PANEL Front panel switch/LED header
9. F_USB1~2 Front panel USB header (F_USB1 supports EZ Charger)
10. CASE CASE open header
11. ME_UNLOCK ME unlock header-for factory use only
12. F_USB3~4 Front panel USB header
13. SPK Speaker header
14. COM Onboard serial port header
15. LPT Parallel port header
16. CLR_CMOS Clear CMOS jumper
17. SYS_FAN System cooling fan connector
18. SPDIFO SPDIF out header
19. F_AUDIO Front panel audio header
20. PCI1~2 32-bit add-on card slot
21. PCIE PCI Express x1 slot
22. PCIEX16 PCI Express x16 slot for graphics interface
23. ATX12V 4-pin +12V power connector
1. CPU Socket
