ECS H67H2-M2 User Manual

4
Introducing the Motherboard
• Intel
®
H67 Express Chipset
• LGA1155 socket for new 2
nd
Generation Intel
®
Core
TM
Fam-
ily/ Pentium/ Celeron processors
• Supports “Hyper-Threading” technology CPU
• DMI 5.0 GT/S
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
Chipset
Memory
CPU
Specifications
• Realtek ALC892 8-Ch HD audio CODEC
• Compliant with HD audio specification
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 1 x D-sub (VGA)
• 2 x USB3.0 ports(USB 3.0 optional & compatible with USB2.0)
• 4 x USB2.0 ports
• 1 x DVI Port (HDMI Port Optional)
• 1 x RJ45 LAN connectors
• 1 x Audio port with 5 audio jacks (Line in, microphone in,
line out) and 1 optical SPDIF out
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 4 x Serial ATA 3Gb/s connectors
• 2 x Serial ATA 6Gb/s connectors
• 1 x Front panel switch/LED header
• 1 x Front panel audio header
• 1 x Speaker header
• 4 x USB2.0 headers support additional 8 USB ports (F_USB1
supports EZ Charger)
• 1 x Clear CMOS header
• 1 x LPT header
• 1 x COM header
• 1 x SPDIF out header
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
Audio
Giga LAN
Internal I/O
Connectors &
Headers
Rear Panel I/O
• Realteck 8111E Gigabit Lan (10/100 Lan optional)
• Supported by Intel
®
H67 Chipsets
• 4 x SATAII 3.0 Gb/s Host Controllers
• 2 x SATAIII 6.0 Gb/s Host Controllers
Storage
• 1 x PCI Express Gen2 x16 slot
• 1 x PCI Express Gen2 x1 slot
• 2 x PCI slots
Expansion
Slots
• ITE IT8893 Bridge supports two PCI slots expansion
• Etron USB 3.0 Controller supports two USB 3.0 ports at the
back panel (Compatible with USB 2.0)
Extra Chips
(Optional)
