ECS H67H2-M4 - Power Management Setup

35
Using BIOS
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Vcore
• IMC Voltage
• VDIMM
• PCH Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health
events, such as System & CPU temperature, CPU & DIMM voltage, CPU &
system fan speed,... etc.
Press <Esc> to return to the Advanced Menu page.
Power Management Setup
This page sets up some parameters for system power management operation.
+/- : Value
Enter : Select


:Select Screen
:Select Item
Power Management Setup
Resume By RING [Disabled]
Resume By PCI-E/Lan PME [Disabled]
Resume By USB (S3) [Disabled]
Resume By PS2 KB (S3) [Disabled]
Resume By PS2 MS (S3) [Disabled]
EUP Function [Enabled]
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
About Resume by Ring
Resume By RING (Disabled)
An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call
on the modem) awakens the system from a soft off state.
This item is used to set the CPU/system/power fan full speed offset value.
CPU/System/Power Fan Full Speed Offset(-) (23)
Press <Esc> to return to the PC Health Status page.
