Introducing the Motherboard
• Intel
®
H67 Chipset
• LGA1155 socket for 2
nd
Generation Intel
®
Core
TM
Family/
Pentium
®
/Celeron
®
processors
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 Gen2 slot
• 3 x PCI Express x1 Gen2 slots
• Supported by Intel
®
H67 Express Chipset
-2 x Serial ATA 6.0 Gb/s Host Controllers
-4 x Serial ATA 3.0 Gb/s Host Controllers
• Realtek ALC892 8-Ch HD audio CODEC
• Compliant with HD audio specification
• 6 x USB 2.0 ports
• 2 x USB 3.0 ports (Compatible with USB 2.0)
• 1 x DVI port (optional)
• 1 x HDMI port (optional)
• 1 x VGA port
• 1 x RJ45 LAN connector
• 1 x PS/2 keyboard & PS/2 mouse connector
• 1 x Audio port (Line in, microphone in, 8-ch line out and
optical SPDIF out)
Chipset
Memory
Expansion
Slots
Storage
LAN
CPU
Specifications
Rear Panel I/O
• Realteck RTL 8111E Gigabit Lan (Co-lay RTL8105E Lan )
Audio
• Etron USB 3.0 Controller supports two USB 3.0 ports at the
back panel (Compatible with USB 2.0)
Extra Chips
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 4 x Serial SATA 3Gb/s connectors
• 2 x Serial SATA 6Gb/s connectors
• 1 x Front panel switch/LED header
• 1 x Front panel audio header
• 3 x USB 2.0 headers support additional six USB 2.0 ports
(F_USB1 supports EZ charger)
• 1 x ME_UNLOCK header
• 1 x Case Open header
• 1 x COM header
• 1 x SPDIF out header
• 1 x Clear CMOS header
• 1 x buzzer header
• 1 x LDC header
• 1 x LPT header
Internal I/O
Connectors &
Headers
