ECS H77H2-M User Manual

Chapter 3
H77H2-M USER MANUAL
54
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset M.I.B III Boot Security Save&Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Select the keyboard
NumLock state
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
USB CD/DVD
USB Hard Disk
USB Flash:Forza Mot...
Network
USB IDE/Floppy
CD/DVD
UEFI
Boot Configuration
Bootup NumLock State On
Quiet Boot Disabled
Set Boot Priority
1st Boot Hard Disk
2nd Boot
3rd Boot
4th Boot
5thBoot
6thBoot
7th Boot
8th Boot
Hard Disk Drive Priorities [Press Enter]
CD/DVD ROM Drive Priorities [Press Enter]
USB/ IDE Floppy Drive Priorities [Press Enter]
USB CD/DVD ROM Drive Priorities [Press Enter]
USB HardDisk Drive Priorities [Press Enter]
USB Flash Drive Priorities [Press Enter]
NETWORK Device Priorities [Press Enter]
UEFI Boot Drive Priorities [Press Enter]
Boot Configuration
This item shows the information of the Boot Configuration.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Set Boot Priority
This item enables you to set boot priority for all boot devices.
1st/2nd/3rd/4th/5th/6th/7th/8th Boot
These items show the boot priorities.
Hard Disk / CD/DVD ROM / USB/IDE Floppy / USB CD/DVD ROM / USB HardDisk / USB
Flash / NETWORK / UEFI Boot Drive Priorities
These items enable you to specify the sequence of loading the operating system.
Press <Enter> to see the submenu.
