Chapter 3
H81H3-M USER MANUAL
33
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
CPU Smart Fan/System Smart Fan Control (Enabled)
These items enable you to define the CPU smart fun/system smart fan by smartly
adjusting the CPU smart fan/system smart fan. When it is set at certain tempera-
ture, the CPU smart fan/system smart fan PWM value will change accordingly.
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Temperature (DTS) 47
System Temperature 27
O
C
CPU Fan Speed 3629RPM
System Fan Speed 0 RPM
Processor Input Voltage 1.728 V
DIMM Voltage 1.524V
TCC Activation Temperature (DTS) 75
Smart Fan Function
PC Health Status
Main Advanced Chipset M.I.B. III Boot Security Exit
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value / unite
CPU Fan Full Speed Offset (DTS) 52
System Smart Fan Control Enabled
Smart Fan Mode Normal
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS) 45
DeltaT +3
Smart Fan Slope PWM value 10 PWM value / unite
System Fan Full Speed Offset (DTS) 52
Enable CPU Smart Fan
