ECS H81H3-M User Manual

Chapter 3
H81H3-M USER MANUAL
40
SATA Port1~4 (Not Present)
This motherboard supports four SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
Press <Esc> to return to the Advanced Menu page.
/Click: Select Item
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
F1: General Help
F Disabled2:
PreviouDisableds
Values
F3: Optimized Defaults
F4: Save & Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
F1: General Help
F2: Previous Values
ESC/Right Click: Exit
Main Advanced Chipset M.I.B. III Boot Security Exit
/Click: Select Item
F3: Optimized Defaults
F4: Save & Exit
Spin up Device (Disabled)
On an edge detect from 0 to 1, the PCH starts a COMRESET initization sequence to the
device.
SATA Mode (AHCI Mode)
Use this item to select SATA mode.
SATA Configuration
SATA Mode AHCI Mode
SATA Port1
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port2
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port3
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port4
Not Present
Spin Up Device Disabled
External SATA Disabled
Determines how SATA control-
ler(s) operate.
External SATA (Disabled)
Use this item to enable or disable External SATA Support.
