This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B. III (MB Intelligent BIOS III) Menu
CPU OverClocking Configuration
Scroll to this item to view the following screen:
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking Configu-
ration
M.I.B. III (MB Intelligent BIOS III)
CPU OverClocking Configuration
North Bridge Configuration
Memory Configuration
Over Voltage Configuration
Spread Spectrum Auto
Intel (R) Core (TM) i7-4765T CPU @ 2.00GHZ
Processor Speed 2000 MHz
Memory Frequency 1067 MHz
Total Memory 4096 MB (DDR3 )
Main Advanced Chipset M.I.B. III Boot Security Exit
CPU Ratio 20
Package Current Lock Disabled
IA Core Current Maximum
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Runtime Turbo Enable Disabled
Boot performance mode Max Non-Turbo Perfor...
Package TDP Lock Enable Disabled
Long Duration Power Limit Override Maximum
Power Limit 1 Time(Second) 8
Power Limit 2 Switch Enabled
Short Duration Power Limit Override Maximum
1 Core Ratio Limit 30
2 Core Ratio Limit 29
3 Core Ratio Limit 27
4 Core Ratio Limit 26
Disable OverClocking Lock Enabled
Package Current Lock
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Ratio (20)
This item allows users to control non turbo CPU ratio.
Package Current Lock (Disabled)
This item allows you to enable or disable the package current lock.
